Gerace Construction undertook a gate replacement project at the Tom Miller Dam in Austin, Texas. While working on Large Gate #6, and after installing a needle beam cofferdam system to lower the water level, a continuous wet spot was discovered under the metal gate sill. This indicated a crack in the concrete extending under the sill plate. Sealing the leak was necessary to prepare and coat the steel sill plate, which was crucial for the overall gate replacement.
Initial Assessment
The primary challenge was water seeping through a crack, less than one linear foot in length, located in the concrete beneath the steel gate sill. The cofferdam system had created approximately 18 feet of head pressure upstream, with the water level pumped down about two feet below the sill. As per the project specifications, a dry surface was required to apply coatings to the steel sill plate.
Proposed Solution
Alchatek recommended Spetec PUR H100 to seal the crack. This hydrophobic polyurethane resin was chosen for its ability to rapidly seal cracks with reasonable water flow and minimal anticipated movement. The solution involved injecting the resin into the crack to create a watertight seal, allowing the steel surface to dry for coating application. Alchatek also provided an on-site representative during the injection process, as required by the project specifications.
Procedures
1. Preparation:
- The contractor established the cofferdam system and lowered the water level to expose the leaking area.
- Injection ports were installed along the crack at 12-inch centers on alternating sides.
2. Injection Process:
- Spetec PUR H100 mixed with Alchatek Gen Cat was injected into the crack using positive displacement equipment capable of maintaining a minimum pressure of 250 psi.
- Injection began at the lowest port and continued sequentially upward until grout filled the crack and seepage ceased.
- Inline pressure was monitored throughout to ensure it did not drop below 190 psi during injection.
3. Post-Injection:
- The injected resin was allowed to cure fully, forming a watertight seal.
- Excess surface seal material was removed, and the repaired area was inspected to confirm no further water intrusion.
- The injection ports were removed, and holes were patched flush with hydraulic cement as per project guidelines.
Results
The application of Spetec PUR H100 successfully sealed the leak under the steel gate sill, allowing Gerace Construction to proceed with surface preparation and coating application. The fast-reacting properties of Spetec PUR H100 minimized delays while ensuring long-term durability against water infiltration. The Lower Colorado River Authority (LCRA) engineering staff approved of the product, and the Alchatek representative provided the required on-site supervision ensured compliance with all quality assurance measures, resulting in a successful repair that restored functionality and structural integrity to Gate #6 at Tom Miller Dam.
